Industrial barrier paper
INNPAD™

Industrial barrier paper

KEY BENEFITS
  • Impenetrable Solvent Barrier - Effectively blocks amino, acrylic, and polyurethane paints to prevent liquid bleed-through and eliminate costly rework.

  • Zero Lint & Dust-Free - Leaves no paper fibres or powdery residue on the workpiece, significantly reducing the need for post-spray sanding and polishing.

  • Exceptional Thermal Stability - Maintains structural integrity during high-temperature baking processes without shrinking, embrittling, or carbonising.

  • High Conformability - Superbly pliable and easy to tear by hand, allowing for rapid, precise wrapping of curved, flat, and intricate metal components.

Request Bulk Pricing
Specifications

Technical Specifications

Every Roll Is Milled To A Documented Specification. Request The Full Technical Data Sheet With Your Quote.

Grammage
30 - 80 g/m² (±5%)
Moisture
6% (+2)
Thickness
45 - 110 µm (+5)
Tensile Strength (MD / CD)
MD: ≥ 31-91 N/15mm / CD: ≥ 16-53 N/15mm
Stretch (MD / CD)
MD: ≥ 1.8% / CD: ≥ 4.0%
Tearing Resistance (MD / CD)
MD: ≥ 100-800 mN / CD: ≥ 120-850 mN
Bursting Strength
≥ 105 - 305 kPa
Cobb Value (PS / RS)
PS: ≤ 28 g/m² / RS: ≤ 30 g/m²
Smoothness (PS / RS)
PS: ≥ 15 S / RS: ≥ 15 S
Kit Level
≥ 5
Waterproof Test
10s without penetration
OBA
Negative
Odour
≤ 1
Core Performance Features

Engineered for Flawless Industrial Coating

Absolute Defence Against Chemical Solvents

Absolute Defence Against Chemical Solvents

Formulated to block a wide spectrum of harsh chemical liquids, including aggressive amino, acrylic, and polyurethane paints. This dense barrier completely prevents paint penetration, ensuring crisp colour separation and safeguarding the underlying workpiece from contamination.

Stable Under High-Temperature Baking

Stable Under High-Temperature Baking

Unlike standard masking papers, our barrier paper remains entirely stable during high-temperature curing and baking stages. The coating is engineered to not flake, shrink, or carbonise, guaranteeing that no impurities drop onto your pristine, freshly painted surfaces.

Enhanced Production Efficiency

Enhanced Production Efficiency

Designed to be completely lint-free and low-dust. By preventing loose paper fibres from adhering to the sprayed workpiece, it drastically reduces the time, labour, and associated costs required for post-process surface repair and polishing.

Absolute Defence Against Chemical Solvents
Absolute Defence Against Chemical Solvents

Absolute Defence Against Chemical Solvents

Formulated to block a wide spectrum of harsh chemical liquids, including aggressive amino, acrylic, and polyurethane paints. This dense barrier completely prevents paint penetration, ensuring crisp colour separation and safeguarding the underlying workpiece from contamination.

Stable Under High-Temperature Baking
Stable Under High-Temperature Baking

Stable Under High-Temperature Baking

Unlike standard masking papers, our barrier paper remains entirely stable during high-temperature curing and baking stages. The coating is engineered to not flake, shrink, or carbonise, guaranteeing that no impurities drop onto your pristine, freshly painted surfaces.

Enhanced Production Efficiency
Enhanced Production Efficiency

Enhanced Production Efficiency

Designed to be completely lint-free and low-dust. By preventing loose paper fibres from adhering to the sprayed workpiece, it drastically reduces the time, labour, and associated costs required for post-process surface repair and polishing.
